Laser-MS12-16

Product Features

  • Based on Sharp laser chip, ultra-bright 515nm green laser source, working distance up to 20 meters, with 3 levels of laser brightness adjustment to adapt to different ambient light conditions.
  • Multiple 360-degree circular laser lines cover horizontal and vertical directions comprehensively, completing multi-angle leveling calibration at once without the need for repeated adjustments, saving a lot of operation time.
  • The laser projection window can rotate 360 degrees continuously and is detachable, making it convenient for adjusting and cleaning maintenance for different usage angles.
  • Designed with a universal TYPE-C interface for convenient charging.
  • The body is wrapped in high-quality soft rubber, preventing damage from falls, providing comfortable and non-slip grip, ensuring safe and reliable operation.
  • Battery level display with built-in battery indicator light, allowing real-time monitoring of remaining battery capacity to avoid sudden power failure during use.

Technical Parameters

  • Product Model
  • Toway Laser-MS12 WCG
  • Toway Laser-MS12 FCG
  • Toway Laser-MS16 CG
  • Beam Color
  • Green
  • Green
  • Green
  • Laser Class
  • 2
  • 2
  • 2
  • Laser Wavelength
  • 515nm
  • 515nm
  • 515nm
  • Emitting Angles
  • 3 x 360°
  • 3 x 360°
  • 4 x 360°
  • Protection Grade
  • IP54
  • IP54
  • IP54
  • Self-levelling and Alarm
  • 3°(Alarm)
  • 3°(Alarm)
  • 3°(Alarm)
  • Operating Distance
  • 20m
  • 20m
  • 20m
  • Leveling Accuracy
  • ±1.5mm/7m
  • ±1.5mm/7m
  • ±1.5mm/7m
  • Body Weight
  • 0.32kg
  • 0.32kg
  • 0.32kg
  • Package Weight
  • 1.1kg
  • 1.1kg
  • 1.1kg
  • Package Size (mm)
  • 180 x 150 x 145
  • 180 x 150 x 145
  • 180 x 150 x 145
  • Battery Type
  • 5V 2400mAh x 2
  • 5V 2400mAh x 2
  • 5V 2400mAh x 2
  • Operating Hours
  • 5h
  • 5h
  • 5h
  • Tripod Support
  • Y
  • Y
  • Y
  • Tripod Interface
  • 5/8"
  • 5/8"
  • 5/8"
  • Operating Temperature
  • -10 ~ 40°C
  • -10 ~ 40°C
  • -10 ~ 40°C
  • Brightness Levels
  • 3
  • 3
  • 3

Accessories

  • Body
  • Mini Wall Mount Bracket + Iron Piece
  • Mini Plastic Lifting Platform
  • Two 2400 mAh Battery Packs
  • Charger
  • Manual
