ProductLaser-M

Laser-MM12-16

mm12-16
mm12-16
mm12-16

Laser-MM12-16

Product Features

  • Based on Sharp laser chip, ultra-bright 515nm green laser source, working distance up to 20 meters, with 4 levels of laser brightness adjustment to adapt to different ambient light conditions.
  • Multiple 360-degree circular laser lines cover horizontal and vertical directions comprehensively, completing multi-angle leveling calibration at once without the need for repeated adjustments, saving a lot of operation time.
  • Touch button panel with highly sensitive touch buttons for simple and intuitive operation.
  • The lens prism is made of high-quality copper material plated with nickel. Durable and corrosion-resistant, ensuring precise laser projection.
  • Equipped with a two-in-one lifting platform for quick adjustment of instrument height, suitable for various working environments. It also comes with a rotating base for convenient multi-angle operation.
  • Encapsulated machine body design, shockproof and moisture-proof, suitable for outdoor operations.

Technical Parameters

  • Product Model
  • Toway Laser-MM12 WCG
  • Toway Laser-MM12 FCG
  • Toway Laser-MM16 CG
  • Beam Color
  • Green
  • Green
  • Green
  • Laser Class
  • 2
  • 2
  • 2
  • Laser Wavelength
  • 515nm
  • 515nm
  • 515nm
  • Emitting Angles
  • 3 x 360°
  • 3 x 360°
  • 4 x 360°
  • Protection Grade
  • IP54
  • IP54
  • IP54
  • Self-levelling and Alarm
  • 3°(Alarm)
  • 3°(Alarm)
  • 3°(Alarm)
  • Operating Distance
  • 20m
  • 20m
  • 20m
  • Leveling Accuracy
  • ±1.5mm/5m
  • ±1.5mm/5m
  • ±1.5mm/5m
  • Body Weight
  • 0.6kg
  • 0.6kg
  • 0.6kg
  • Package Weight
  • 1.6kg
  • 1.6kg
  • 1.6kg
  • Package Size (mm)
  • 200 x 200 x 195
  • 200 x 200 x 195
  • 200 x 200 x 195
  • Battery Type
  • 5V 2400mAh x 2
  • 5V 2400mAh x 2
  • 5V 2400mAh x 2
  • Operating Hours
  • 5h
  • 5h
  • 5h
  • Tripod Support
  • Y
  • Y
  • Y
  • Tripod Interface
  • 5/8"
  • 5/8"
  • 5/8"
  • Operating Temperature
  • -10 ~ 40°C
  • -10 ~ 40°C
  • -10 ~ 40°C
  • Brightness Levels
  • 4
  • 4
  • 4

Accessories

  • Body
  • Wall Mount Bracket (with Iron Piece)
  • Two-in-One Lifting Platform
  • Remote Control
  • Charger
  • Two 2400 mAh Battery Packs
  • Manual
